Aluminized Polyimide Film

Description

Harnawa Insulations Private Limited is a manufacturer of aluminized polyimide film in India, supplying this metallised kapton-type PI film to aerospace companies, satellite system integrators, electronics manufacturers and industrial thermal management suppliers across India and internationally. Aluminized polyimide film combines the flexibility and high-temperature stability of kapton-type polyimide film with the EMI shielding and thermal spreading of a sputtered aluminium layer — creating a dual-function material with one conductive side and one insulating side.

Whether you need metallised polyimide film for satellite multi-layer insulation (MLI), flexible circuit EMI shielding, heat spreader film or industrial thermal barriers, Harnawa supplies aluminized PI film in 25–250 μm thicknesses with custom slit widths available.

What is Aluminized Polyimide Film?

Aluminized polyimide film is a composite material where a thin layer of aluminium is deposited by physical vapour deposition (sputtering) onto a kapton-type polyimide film base. The result is a film with two functionally different sides: the aluminium side is electrically conductive and provides EMI shielding and thermal conductivity; the polyimide side is electrically insulating and provides the structural film layer with -269°C to 400°C temperature performance.

This combination makes aluminized polyimide film the standard material for spacecraft multi-layer insulation (MLI blankets), where multiple layers of aluminised kapton film are stacked to create highly effective thermal insulation for satellites and space vehicles.

Structure	Sputtered aluminium layer on kapton-type polyimide film base
Aluminium Side	Conductive — EMI shielding and thermal spreading
Polyimide Side	Insulating — electrical isolation and mechanical support
Temperature Range	-269°C to +400°C
Flame Retardancy	UL 94 V-0, halogen-free, RoHS/REACH compliant

Polyimide Film Types & Grades — Full Range

Harnawa manufactures the complete range of kapton-type polyimide film grades. Aluminized PI Film (highlighted below) is engineered for EMI shielding and thermal management:

Grade / Series	Type Code	Description & Key Use
HN Series	Standard	Standard kapton-type polyimide film, 0.5–10 mil.
FEP Coated Film	FH / FHF	FEP coated polyimide film — heat sealable.
Black PI Film	BX / BY / BL	Opaque black polyimide film, 13–125 μm.
ESD PI Film	Functional	Anti-static polyimide film for PCB protection.
Aluminized PI Film — This Product	Functional	Sputtered aluminium on kapton-type polyimide film. 25–250 μm. One side conductive (EMI/thermal), one side insulating. For aerospace MLI, EMI shielding, thermal management.
CR Film	CR / FCR / FCRF	Corona resistant polyimide film, ≥80 hr. For VFD motors.
Thermal-Conductive	MT Series	Polyimide film with thermal conductivity >0.36 W/m·K.
NHN Composite	Laminate	Non-woven/polyimide film/non-woven. Breakdown: 8–10 kV.
Colourful PI Film	Specialty	Red, Green and Transparent polyimide film.
Voice Coil Film	Specialty	High stability polyimide film for voice coil formers.

Typical Applications of Aluminized Polyimide Film

Aerospace

Satellite thermal blankets (MLI)
Spacecraft thermal control
Launch vehicle insulation
Cryogenic tank insulation
Solar array backing film

Electronics

Flexible circuit EMI shielding
FPC shielding layer
Cable EMI wrap
PCB ground plane film
RF shielding applications

Thermal Management

Heat spreader film
Thermal interface material
LED heat dissipation film
EV battery thermal management
Power module thermal film

Industrial

High-temp radiant barriers
Industrial thermal blankets
Military electronics shielding
Medical device shielding
Furnace insulation film

Aluminized polyimide film applications — aerospace thermal blankets and EMI shielding

Metallised kapton type aluminized polyimide film for electronics and aerospace India

Key Features & Benefits

EMI Shielding: Sputtered aluminium layer provides effective electromagnetic interference shielding
Dual-Function Surface: Conductive Al side for shielding and heat spreading; insulating PI side for electrical isolation
Lightweight: Thin sputtered Al — no heavy metal foil weight — ideal for aerospace applications
Wide Thickness Range: 25–250 μm total thickness
Same Kapton Temperature Range: -269°C to +400°C
RoHS / REACH Compliant: Safe for export to EU, USA and global markets

Technical Specifications — Aluminized Polyimide Film

Structure	Kapton-type polyimide film + Sputtered aluminium layer
Thickness Range	25–250 μm (total including Al layer)
Al Side Property	Conductive — EMI shielding and thermal spreading
PI Side Property	Insulating — electrical isolation
Temperature Range	-269°C to +400°C
Standard Width	520 mm (custom available)
Compliance	CE, RoHS/REACH, ISO 9001, ISO 14001, UL 94 V-0

Certifications & Compliance

SAFETY

CE ListedEuropean Conformity — required for all EU market sales

MILITARY

Mil-P-46123Type 1, Item A — US Military performance specification

ENVIRONMENT

RoHS CompliantRestriction of Hazardous Substances — EU directive

CHEMICAL

REACH CompliantEU Chemical Safety regulation for export markets

FLAME

UL 94 V-0Highest flame retardancy rating — self-extinguishing

QUALITY

ISO 9001International quality management system certification

ENVIRONMENT

ISO 14001Environmental management system certification

SAFETY

Halogen-FreeNo chlorine, fluorine or bromine — safe for all markets

Why Buy Aluminized Polyimide Film from Harnawa Insulations?

Manufacturer — Not a Trader

We manufacture aluminized polyimide film directly — better pricing and faster lead times than import traders.

Wide Thickness Range

25–250 μm aluminized polyimide film available. Custom thickness and slit width on request.

Pan-India Supply

Fast dispatch from Bhiwandi to aerospace, electronics and industrial customers across India.

Export Ready

Exporting to USA, UK, UAE, Germany, Singapore, Malaysia and more.

Supply & Packaging

Standard Width: 520 mm | Custom slit widths available
Roll Length: 1500 m standard | Custom lengths available
Storage: 15°C–30°C, 40%–70% RH, away from sunlight
Shelf Life: 24 months from manufacture date
Lead Time: 2–5 working days (standard) | 7–14 days (custom)

Related Polyimide Film Products

HN Polyimide Film — Standard kapton-type amber PI film
Thermal Conductive Polyimide Film — MT Series for heat dissipation
Black Polyimide Film — Opaque black polyimide film for EMI shielding
FEP Polyimide Film — Heat sealable FEP coated polyimide film

Frequently Asked Questions — Aluminized Polyimide Film

What is aluminized polyimide film used for?

Aluminized polyimide film is used for satellite and spacecraft multi-layer insulation (MLI), flexible circuit EMI shielding, aerospace thermal blankets, heat spreader films in LED and power electronics, industrial thermal barriers and military electronics shielding. The aluminium side provides shielding/thermal conductivity; the kapton-type polyimide side provides insulation.

Is aluminized polyimide film a kapton-type film?

Yes. The base film is kapton-type PMDA-ODA polyimide film with a sputtered aluminium layer deposited on one side. The polyimide base provides the same temperature range (-269°C to 400°C) and electrical insulation as standard kapton film; the aluminium layer adds EMI shielding and thermal conductivity.

What is the price of aluminized polyimide film in India?

Price depends on thickness, width and order quantity. Contact us at enquiry@harnawainc.com or WhatsApp +91 7276671876 for pricing on aluminized polyimide film in India.
