Colourful PI Film
Colourful PI Film
Colourful PI Film manufacturer in India — INSOURCES EXIM PVT LTD. Red, Green and Transparent polyimide film. Thickness 25–50 μm. Colour stable at high temperature — no fading up to 400°C. For circuit identification, colour-coded insulation and high-temperature labels. CE, RoHS certified. Pan-India supply.
Priced per requirement — tell us grade, width, thickness and quantity and we quote against it.
INSOURCES EXIM PVT LTD is a manufacturer of colourful polyimide film in India, supplying Red, Green and Transparent kapton-type PI film to electronics manufacturers, PCB fabricators, wire and cable producers and industrial labelling companies across India and internationally. Unlike standard amber kapton polyimide film, colourful polyimide film is manufactured with colour incorporated directly into the PMDA-ODA polymer — providing permanent, heat-stable colour that does not fade or transfer even at temperatures up to 400°C.
Whether you need red polyimide film, green polyimide film or transparent PI film for circuit identification, colour-coded insulation or high-temperature labels, INSOURCES supplies all three colours in 25–50 μm thicknesses directly from our Bhiwandi facility.
What is Colourful Polyimide Film?
Colourful polyimide film is a speciality variant of kapton-type polyimide film where pigments are compounded directly into the PMDA-ODA polymer matrix during the film casting process — not surface-dyed or coated. The colour is part of the film itself and therefore inherits all the thermal and chemical properties of the polyimide polymer, including stability to 400°C and UL 94 V-0 flame retardancy.
Three colours are available as standard: Red, Green and Transparent. Transparent polyimide film is optically clear unlike standard amber kapton film, making it suitable for optical and display applications where visibility through the film is required. All three variants share the same thickness range of 25–50 μm and standard width of 520 mm.
| Available Colours | Red, Green, Transparent (clear) |
| Colour Method | Pigment in polymer matrix — not surface dyed or coated |
| Colour Stability | Stable to 400°C — no fading, no colour transfer |
| Temperature Range | -269°C to +400°C |
| Flame Retardancy | UL 94 V-0, halogen-free, RoHS/REACH compliant |
Polyimide Film Types & Grades — Full Range
INSOURCES manufactures the complete range of kapton-type polyimide film grades. Colourful PI Film (highlighted below) is available in Red, Green and Transparent for colour-coded identification applications:
| Grade / Series | Type Code | Description & Key Use |
| HN Series | Standard | Standard amber kapton-type polyimide film, 0.5–10 mil. |
| FEP Coated Film | FH / FHF | FEP coated polyimide film — heat sealable. |
| Black PI Film | BX / BY / BL | Opaque black polyimide film, 13–125 μm. |
| ESD PI Film | Functional | Anti-static polyimide film for PCB protection. |
| Aluminized PI Film | Functional | Sputtered aluminium polyimide film for EMI shielding. |
| CR Film | CR / FCR / FCRF | Corona resistant polyimide film, ≥80 hr. For VFD motors. |
| Thermal-Conductive | MT Series | Polyimide film with thermal conductivity >0.36 W/m·K. |
| NHN Composite | Laminate | Non-woven/polyimide film/non-woven. Breakdown: 8–10 kV. |
| Colourful PI Film — This Product | Specialty | Red, Green and Transparent kapton-type polyimide film. Colour stable to 400°C. 25–50 μm. For circuit identification, colour-coded insulation and high-temperature labels. |
| Voice Coil Film | Specialty | High stability polyimide film for voice coil formers. |
Typical Applications of Colourful Polyimide Film
- Phase identification (R/G)
- Colour-coded wire insulation
- Circuit marking tape
- Motor winding identification
- Terminal colour marking
- Colour-coded FPC substrates
- PCB layer identification
- Visual inspection film
- Coverlay colour coding
- Assembly marking film
- High-temperature colour labels
- Industrial colour marking
- Equipment identification
- Safety colour marking tape
- Process identification labels
- Optical applications
- Display protective film
- Sensor window film
- UV-stable clear film
- Transparent insulation
Key Features & Benefits
- Permanent Colour: Pigment in polymer matrix — colour is part of the film, not a coating. No fading or transfer to 400°C
- Three Colours Available: Red, Green and Transparent — for colour-coded identification and circuit marking
- High Temperature Stable: Colour retained throughout the full kapton-type temperature range to 400°C
- Thin Film: 25–50 μm — ideal for labelling, identification and coverlay applications
- Transparent Grade: Optically clear — unlike standard amber kapton film — for visibility-required applications
- RoHS / REACH Compliant: Safe for export to EU, USA and global markets
Technical Specifications — Colourful Polyimide Film
| Available Colours | Red, Green, Transparent |
| Thickness Range | 25–50 μm |
| Colour Stability | Stable to 400°C — polymer-integrated pigment |
| Tensile Strength | Up to 170 MPa |
| Temperature Range | -269°C to +400°C |
| Standard Width | 520 mm (custom slit widths available) |
| Flame Rating | UL 94 V-0, Halogen-Free |
Certifications & Compliance
CE ListedEuropean Conformity — required for all EU market sales
Mil-P-46123Type 1, Item A — US Military performance specification
RoHS CompliantRestriction of Hazardous Substances — EU directive
REACH CompliantEU Chemical Safety regulation for export markets
UL 94 V-0Highest flame retardancy rating — self-extinguishing
ISO 9001International quality management system certification
ISO 14001Environmental management system certification
Halogen-FreeNo chlorine, fluorine or bromine — safe for all markets
Why Buy Colourful Polyimide Film from INSOURCES Insulation?
Manufacturer — Not a Trader
We manufacture colourful polyimide film directly — better pricing and faster lead times than importers.
All 3 Colours in Stock
Red, Green and Transparent polyimide film in 25–50 μm. Custom colours on enquiry.
Pan-India Supply
Fast dispatch from Bhiwandi to electronics and cable manufacturers across India.
Export Ready
Exporting to USA, UK, UAE, Germany, Singapore, Malaysia and more.
Supply & Packaging
- Standard Width: 520 mm | Custom slit widths available
- Roll Length: 1500 m standard | Custom lengths available
- Storage: 15°C–30°C, 40%–70% RH, away from sunlight
- Shelf Life: 24 months from manufacture date
- Lead Time: 2–5 working days (standard) | 7–14 days (custom)
Related Polyimide Film Products
- HN Polyimide Film — Standard amber kapton-type PI film
- Black Polyimide Film — Opaque black polyimide film
- FEP Polyimide Film — Heat sealable polyimide film
- PI Film Voice Coil — High dimensional stability polyimide film
Frequently Asked Questions — Colourful Polyimide Film
What is colourful polyimide film used for?
Is colourful polyimide film a kapton-type film?
Does the colour fade at high temperature?
What is the price of colourful polyimide film in India?
About INSOURCES EXIM PVT LTD
INSOURCES EXIM PVT LTD is a manufacturer of polyimide films and polyimide products based in Bhiwandi, Maharashtra, India. We supply the complete range of kapton-type PI films across India and internationally. polyimidefilms.com is owned and maintained by INSOURCES EXIM PVT LTD. Contact info@insrcs.com or visit insrcs.com.
